Product Details
product name:
Features:
Designed for mass production of 18650 is designed for spot welding, it will be welded by means of special fixtures fixed batteries, and then into the appropriate nickel plate welded connection, spot welding can be automatically X / Y axis positioning, welding, machine welding speed, solder and nickel plate neat, solder joint appearance, so welding quality packs and battery has a huge promotion, is the majority group and battery manufacturers Required equipment.
Product parameters:
Model : TWSL-400
Welding current : 0-99 Adjustable
power input : AC220V ± 10% / 50Hz
Welding time : 1.0-3.0 (m S)
Output Power : 10KVA
Electrode applied pressure : 0.5-4kgf
Drive Type : Stepper motor
Electrode diameter : ∮3
X / Y-axis moving range : 300 * 300mm (can be customized)
Electrode stroke : 15 mm
Welding parameters:
Model : TWSL-200
Power : 10KVA (max)
Input Frequency : 50/60H
Input voltage : 220VAC
Input gas source : 7-8 Bar (kg / cm)
Primary current : 5-30A
Primary short-circuit current: 1500A
The whole structure : Integrated structure
Welding arm structure: Telescopic swing control
Electrodes to the body distance: 100 mm (Scalable adjustable)
Cylinder diameter : 20 mm
The number of pulses : 0-9
Pulse energy level : 0-99
Automatic compensation range : + 40V - 40V
Digital display panel : 7-segment LED display
External dimensions : 445 * 224 * 343 mm
Gross weight : 42 kg
if you like to know more about the welder machine ,please click :lithium battery automatic spot welding
if you want to know more other machine ,please click : low pressure injection machine
|
|
XY axis battery pack automatic welder , 18650,26650 CNC automatic spot welding machine Images
|
